- “A saturated grease filter looks clean and passes almost no air”
- “Recirculating hoods have a charcoal filter behind the grille”
- “Samsung publishes no codes for hoods, so this is diagnosed by hand”
Symptom
Samsung range hood not extracting
Filters, duct, damper — in that order, and usually the first. A saturated filter kills airflow long before it looks dirty enough to matter. And on a recirculating installation there is a second filter that most owners have never seen.
- From $95 diagnostic, credited to the repair
- 59 cities and neighborhoods covered
- OEM parts available on order
- In writing the price, before anything is opened
Five ordinary causes
What this usually turns out to be
Cheapest and commonest first, which is also the order we check them in. They sit hundreds of dollars apart, and only the unit settles which one is yours.
-
Saturated grease filters
The most common cause and the cheapest.
Over the range microwave vent service from $125 -
The charcoal filter
On recirculating installations only, and rarely replaced.
Over the range microwave vent service from $125 -
The duct or the outside damper
A flap painted shut, or a nest.
Range hood repair from $135 -
The blower
Tested after the filters, because the filters are usually the answer.
Range hood repair from $135 -
A recirculating installation working normally
Not a repair. Worth knowing before anybody is paid.
Diagnostic visit from $95
In five minutes
Before you call anybody
None of it needs tools, and all of it makes the visit shorter.
-
01
Take the grease filters out and wash them
They go in a dishwasher. Look at the water afterwards.
-
02
Look behind the top grille
A charcoal filter means recirculating, and it needs replacing.
-
03
Go outside while it runs
The damper should be open and you should feel air.
-
04
Hold a tissue to the intake
It should be held there firmly. If it barely holds, airflow is the problem.
How it shows up
What people describe when they call
A shortcut
Narrow it down before anybody arrives
A description of the behaviour leaves a few possible causes. A code names the subsystem before anybody opens anything, which is why it is worth photographing before it clears.
If there is no code at all
The data plate is inside the cabinet, upper left wall or behind the grille. All models
In more detail
About Samsung range hood not extracting
Take both filters out and look
The mesh or baffle filters underneath come out by hand and go in a dishwasher. Then, if the installation recirculates, look behind the top grille for a charcoal filter — it has a life measured in months and almost nobody replaces it. Between them those two account for most of these calls.
What it usually means, by the kind of Samsung appliance
Samsung sells one appliance in several forms, and the same behavior points at different things on each of them. A built-in side-by-side and an integrated column are not the same service situation, and a dual-fuel range and an induction range fail in different halves.
- Ducted — Air goes outside. The duct run and the outside damper are part of the appliance.
- Recirculating — Air is filtered and returned to the room, which will never move as much air as a ducted installation. A great many complaints are this working as designed.
- Over-the-range microwave — The same job done by a different appliance, with the same filters and the same charcoal filter behind the grille.
Ducted and recirculating are different appliances
A ducted hood moves kitchen air outside. A recirculating hood filters it and puts it back into the room — it can take grease and some odor out, but the steam and the heat stay where they were. It will never perform like a ducted installation and it was never going to. Establishing which one you have is the first thing we do, because on a recirculating hood the honest answer to some of these complaints is that nothing is broken.
The filter that hides
Charcoal filters sit behind the top grille, not underneath with the grease filters, and they are a consumable with a life of a few months in a kitchen that cooks. Samsung publishes a replacement procedure for the ones in over-the-range microwaves. In our experience a large majority of recirculating installations have the original one still fitted.
This article is based on:
- Official manufacturer documentation
- Internal repair procedures
- Technician repair history
- Company quality standards
Before you book
Questions about Samsung range hood not extracting
It was fine and now it is not, with no other change.
Filters degrade gradually, so 'suddenly' is often a threshold being crossed rather than a failure. Wash them and see. If nothing changes, then it is the blower or the duct.
There is no duct at all above my hood.
Then it recirculates, and it is doing what it was installed to do. Fresh charcoal will improve it. Converting to ducted is construction rather than repair.
